RIGOL DG1000 Command System
Programming Guide for DG1000
2-22
11. VOLTage:CH2
Syntax VOLTage:CH2 {<amplitude>|MINimum|MAXimum}
Function Set the output amplitude of CH2 and the default unit is Vpp.
Explanation <amplitude> is the amplitude set by users. MIN selects the
minimum amplitude of the specified function and MAX selects the
maximum amplitude.
Unit VPP, VRMS or DBM. Note that DBM could be used only in non-high
resistance. The unit of voltage could be changed via sending
VOLTage:UNIT:CH2.
Example VOLT:CH2 MIN
12. VOLTage:CH2?
Syntax VOLTage:CH2?
Function Query the output amplitude of CH2.
Return Value The query returns the amplitude of the function currently selected
in scientific notation, such as: CH2: 4.000000e-03.
13. VOLTage:HIGH:CH2
Syntax VOLTage:HIGH:CH2 {<voltage>|MINimum|MAXimum}
Function Set the high level of waves output from CH2 and the defualt unit is
V.
Explanation <voltage>is the high level set by users. MIN selects the minimum
high level available and MAX selects the maximum high level
available.
Example VOLT:HIGH:CH2 MAX
14. VOLTage:HIGH:CH2?
Syntax VOLTage:HIGH:CH2?
Function Query the high level of waves output from CH2.
Return Value The query returns the high leve set in scientific notation such as:
1.500000e+00.
15. VOLTage:LOW:CH2
Syntax VOLTage:LOW:CH2 {<voltage>|MINimum|MAXimum}
Function Set the low level of waves output from CH2 and the default unit is
V.
Explanation <voltage>is the low level set by users. MIN selects the minimum
