Rigol DP800 Series Programming Guide

RIGOL Chapter 2 Command System
2-16 DP800 Programming Guide
:MEASure Commands
Command List:
 :MEASure:ALL[:DC]?
 :MEASure:CURRent[:DC]?
 :MEASure:POWEr[:DC]?
 :MEASure[:VOLTage][:DC]?
:MEASure:ALL[:DC]?
Syntax :MEASure:ALL[:DC]? [{CH1|CH2|CH3}]
Description Query the voltage, current and power measured internally on the specified channel.
Parameter
Name Type Range Default
[{CH1|CH2|CH3}] Discrete CH1|CH2|CH3 None
Explanation  If the parameter is omitted, the command queries the voltage, current and
power of the channel currently selected.
 You can send the
:MEASure:CURRent[:DC]?, :MEASure:POWEr[:DC]?
and
:MEASure[:VOLTage][:DC]? commands to query the current, power and
voltage respectively.
Return Format The query returns the voltage, current and power separated by commas, for
example, 5.0000,1.0000,5.000.
Example :MEAS:ALL? CH1 /*Query the voltage, current and power of CH1 and the query
returns 5.0000,1.0000,5.000*/
Related
Commands
:MEASure:CURRent[:DC]?
:MEASure:POWEr[:DC]?
:MEASure[:VOLTage][:DC]?
:MEASure:CURRent[:DC]?
Syntax :MEASure:CURRent[:DC]? [{CH1|CH2|CH3}]
Description Query the output current measured internally on the specified channel.
Parameter
Name Type Range Default
[{CH1|CH2|CH3}] Discrete CH1|CH2|CH3 None
Explanation  If the parameter is omitted, the command queries the current of the channel
currently selected.
 You can send the
:MEASure:POWEr[:DC]? and :MEASure[:VOLTage][:DC]?
commands to query the power and voltage respectively, or send
the
:MEASure:ALL[:DC]? command to query the voltage, current and power at
the same time.
Return Format The query returns the current, for example, 1.0000.
Example :MEAS:CURR? CH1 /*Query the current of CH1 and the query returns 1.0000*/
Related
Commands
:MEASure:ALL[:DC]?
:MEASure:POWEr[:DC]?
:MEASure[:VOLTage][:DC]?

Rigol DP800 Series Specifications

General

Voltage Resolution	1 mV
Current Resolution	1 mA
Overvoltage Protection (OVP)	Yes
Overcurrent Protection (OCP)	Yes
Operating Temperature	0°C to 40°C
Load Regulation (CV)	±(0.01% + 2mV)
Load Regulation (CC)	±(0.02% + 2mA)
Line Regulation (CV)	±(0.01% + 2mV)
Display	LCD
Interface	USB
Protections	OVP, OCP
Remote Control	Yes
Storage Temperature	-20°C to 60°C
Number of Channels	3 (DP831A, DP832, DP832A), 2 (DP821, DP821A)
Output Voltage Range	0-30V (CH1), 0-30V (CH2), 0-5V (CH3 for DP831A/DP832/DP832A), 0-30V (CH1), 0-5V (CH2) (DP821/DP821A)
Output Current Range	0-3A (CH1), 0-3A (CH2), 0-3A (CH3 for DP831A/DP832/DP832A), 0-3A (CH1), 0-3A (CH2) (DP821/DP821A)
Total Power	195W (DP831A, DP832, DP832A), 160W (DP821, DP821A)
Output Power	90W (CH1), 90W (CH2), 15W (CH3 for DP831A/DP832/DP832A), 90W (CH1), 70W (CH2) (DP821/DP821A)
Current Accuracy	±(0.1% + 2mA)
