Rigol DP800 Series Programming Guide

RIGOL Chapter 2 Command System
2-80 DP800 Programming Guide
:TRIGger:OUT:SIGNal
Syntax :TRIGger:OUT:SIGNal [D0|D1|D2|D3,]{LEVEL|SQUARE}
:TRIGger:OUT:SIGNal? [D0|D1|D2|D3]
Description Set the type of the trigger output signal of the specified data line.
Query the type of the trigger output signal of the specified data line.
Parameter
Name Type Range Default
[D0|D1|D2|D3] Discrete D0|D1|D2|D3 D0
{LEVEL|SQUARE} Discrete LEVEL|SQUARE LEVEL
Explanation  If [D0|D1|D2|D3] is omitted, the command sets the type of the trigger output
signal of the data line currently selected.
 When LEVEL is selected, the corresponding data line outputs level signal when
the trigger condition is met; when SQUARE is selected, the corresponding data
line outputs square waveform when the trigger condition is met.
Return Format The query returns LEVEL or SQUARE.
Example :TRIG:OUT:SIGN D1,LEVEL /* Set the type of the trigger output signal of D1 to
level */
:TRIG:OUT:SIGN? D1 /* Query the type of the trigger output signal of D1
and the query returns LEVEL*/
:TRIGger:OUT:SOURce
Syntax :TRIGger:OUT:SOURce [D0|D1|D2|D3,]{CH1|CH2|CH3}
:TRIGger:OUT:SOURce? [D0|D1|D2|D3]
Description Set the control source of the trigger output of the specified data line.
Query the control source of the trigger output of the specified data line.
Parameter
Name Type Range Default
[D0|D1|D2|D3] Discrete D0|D1|D2|D3 D0
{CH1|CH2|CH3} Discrete CH1|CH2|CH3 CH1
Explanation  If [D0|D1|D2|D3] is omitted, the command sets the control source of the
trigger output of the data line currently selected.
 Any channel can be selected as the control source of the trigger output.
Return Format The query returns the control source, for example, CH1.
Example :TRIG:IN:SOUR D1,CH1 /* Set the control source of D1 to CH1*/
:TRIG:IN:SOUR? D1 /* Query the control source of D1 and the query returns
CH1*/
