Rigol DP800 Series Programming Guide

RIGOL Chapter 2 Command System
2-26 DP800 Programming Guide
:MONItor:CURRent[:VALue]
Syntax :MONItor:CURRent[:VALue] {<value>|MINimum|MAXimum}
:MONItor:CURRent[:VALue]? [MINimum|MAXimum]
Description Set the current of the monitor condition.
Query the current of the monitor condition.
Parameter
Name Type Range Default
<value> Real
0 to the maximum
current of the current
channel
0.5*rated current of
the current channel
Return Format The query returns the current of the monitor condition, for example, 4.0000.
Example :MONI:CURR 4 /*Set the current of the monitor condition to 4A*/
:MONI:CURR? /*Query the current of the monitor condition and the query
returns 4.0000*/
Related
Commands
:MONItor:CURRent:CONDition
:MONItor:POWER:CONDition
:MONItor:POWER[:VALue]
:MONItor:VOLTage:CONDition
:MONItor:VOLTage[:VALue]
:MONItor:POWER:CONDition
Syntax :MONItor:POWER:CONDition {<P|>P|NONE}
:MONItor:POWER:CONDition?
Description Set the power monitor condition of the monitor to “<Power” or “>Power”. NONE
indicates that no power monitor condition will be set.
Query the power monitor condition of the monitor.
Parameter
Name Type Range Default
{<P|>P|NONE} Discrete <P|>P|NONE NONE
Explanation  After setting the power monitor condition, sending
the
:MONItor:POWER[:VALue] command can set the power value.
 The actual monitor condition is the logic combination of the voltage, current
and power.
Return Format The query returns “condition”, for example, <P.
Example :MONI:POWER:COND <P /*Set the power monitor condition to “<Power”*/
:MONI:POWER:COND? /*Query the current power monitor condition and the
query returns <P*/
Related
Commands
:MONItor:POWER[:VALue]
:MONItor:CURRent:CONDition
:MONItor:CURRent[:VALue]
:MONItor:VOLTage:CONDition
:MONItor:VOLTage[:VALue]

Rigol DP800 Series Specifications

General

Voltage Resolution	1 mV
Current Resolution	1 mA
Overvoltage Protection (OVP)	Yes
Overcurrent Protection (OCP)	Yes
Operating Temperature	0°C to 40°C
Load Regulation (CV)	±(0.01% + 2mV)
Load Regulation (CC)	±(0.02% + 2mA)
Line Regulation (CV)	±(0.01% + 2mV)
Display	LCD
Interface	USB
Protections	OVP, OCP
Remote Control	Yes
Storage Temperature	-20°C to 60°C
Number of Channels	3 (DP831A, DP832, DP832A), 2 (DP821, DP821A)
Output Voltage Range	0-30V (CH1), 0-30V (CH2), 0-5V (CH3 for DP831A/DP832/DP832A), 0-30V (CH1), 0-5V (CH2) (DP821/DP821A)
Output Current Range	0-3A (CH1), 0-3A (CH2), 0-3A (CH3 for DP831A/DP832/DP832A), 0-3A (CH1), 0-3A (CH2) (DP821/DP821A)
Total Power	195W (DP831A, DP832, DP832A), 160W (DP821, DP821A)
Output Power	90W (CH1), 90W (CH2), 15W (CH3 for DP831A/DP832/DP832A), 90W (CH1), 70W (CH2) (DP821/DP821A)
Current Accuracy	±(0.1% + 2mA)
