RIGOL Chapter 5 Trigger
5-34 DS4000E User’s Guide
b. Press CurrentBit and turn the multi-function knob to select the
bit (behind "Hex") to be operated.
c. Switch the data pattern of the current data bit by pressing the
multi-function knob continuously after you set the CurrentBit.
6. Specify the trigger mode
Press Sweep to select “Auto”, “Normal” or “Single” (please refer to “Trigger
Mode”). The corresponding status light of the trigger mode currently selected in
the trigger control area (TRIGGER) at the front panel turns on.
7. Turn the noise rejection on or off
Press Setting to enter the trigger setting submenu. In this submenu, press
Noise Reject to turn the noise rejection on or off (please refer to “Noise
Rejection”).
