Rigol DS4024E User Manual

RIGOL Chapter 10 Waveform Recording
10-4 DS4000E User’s Guide
recording operation. You cannot set the end frame and interval after the
recording operation starts.
1) Start the recording operation
Press Operate to select “●” or press the recording shortcut key ( ) at the
front panel; the oscilloscope starts recording according to the current
settings.
During the recording process, the backlight of the recording shortcut key (
)
is illuminated in red and flashes continuously. The number of frames
currently recorded is displayed in the recording information at the
upper-right side of the screen.
2) Stop the recording operation
 Stop manually
During the recording process, press Operate to select “■” or press the
stop shortcut key (
) at the front panel; the oscilloscope stops
recording.
 Stop automatically
The oscilloscope will stop recording automatically after the specified
number of frames (End Frame) are recorded.
When the recording operation stops, the backlight of the stop shortcut key
(
) is illuminated in orange. When the recording operation is started again,
the number of frames will start from 0.
