Rigol DS4024E User Manual

RIGOL Chapter 16 Specifications
16-2 DS4000E User’s Guide
Horizontal
Time Base Scale DS4024E: 2 ns/div to 1 ks/div
DS4014E: 5 ns/div to 1 ks/div
Deviation between
Channels
1 ns (typical), 2 ns (maximum)
Max. Recording Length 14 Mpts for each channel
Time Base Accuracy
[1]
≤ ±4 ppm
Clock Drift ≤ ±2 ppm/year
Delay Range Pre-trigger (negative delay):
Memory Depth/Sample
Rate
Post-trigger (positive delay): 1 s to 100 ks
Time Base Mode Y-T, X-Y, Roll, Delayed
Number of X-Ys 2 paths at the same time
Waveform Capture
Rate
[2]
60,000 wfms/s
Zero Offset ±0.5 div*minimum time base scale
Vertical
Bandwidth (-3 dB) (50
Ω)
DS4024E: DC to 200 MHz
DS4014E: DC to 100 MHz
Single Bandwidth (50
Ω)
DS4024E: DC to 200 MHz
DS4014E: DC to 100 MHz
Vertical Resolution 8 bits
Vertical Scale 1 MΩ input impedance: 1 mV/div to 5 V/div
50 Ω input impedance: 1 mV/div to 1 V/div
Offset Range 1 MΩ input impedance:
1 mV/div to 225 mV/div: ±2 V
230 mV/div to 5 V/div: ±40 V
50 Ω input impedance:
1 mV/div to 124 mV/div: ±1.2 V
126 mV/div to 1 V/div: ±12 V
Dynamic Range ±5 div
Bandwidth Limit
[1]
DS4024E: 20 MHz/100 MHz
DS4014E: 20 MHz

Rigol DS4024E Specifications

General

Brand	Rigol
Model	DS4024E
Category	Test Equipment
Language	English
