Rigol DS4024E User Manual

Chapter 16 Specifications RIGOL
DS4000E User’s Guide 16-3
Low Frequency
Response
(AC coupling, -3 dB)
≤5 Hz (on BNC)
Calculated Rise Time
[1]
DS4024E: 1.8 ns
DS4014E: 3.5 ns
DC Gain Accuracy ±2% full scale
DC Offset Accuracy
200 mV/div to 5 V/div: ±0.1 div ± 2 mV ± 0.5% offset
1 mV/div to 195 mV/div: ±0.1 div ± 2 mV ± 1.5% offset
ESD Tolerance ±2 kV
Channel-to-Channel
Isolation
DC to maximum bandwidth: >40 dB
Trigger
Trigger Level Range
Internal: ±6 div from the center of the screen
EXT: ±0.8 V
Trigger Mode Auto, Normal, Single
Holdoff Range 100 ns to 10 s
High Frequency
Rejection
[1]
50 kHz
Low Frequency
Rejection
[1]
5 kHz
Edge Trigger
Edge Type Rising, Falling, Rising&Falling
Pulse Trigger
Pulse Condition Positive Pulse Width (greater than, lower than, within
the specific interval);
Negative Pulse Width (greater than, lower than, within
the specific interval)
Pulse Width Range 4 ns to 4 s
Runt Trigger
Pulse Polarity Positive, Negative
Qualifier None, >, <, <>
Pulse Width Range 4 ns to 4 s
Nth Edge Trigger
Edge Type Rising, Falling
