Page #320 background image
RIGOL Chapter 16 Specifications
16-4 DS4000E User’s Guide
Idle Time 40 ns to 1 s
Number of Edges 1 to 65535
Slope Trigger
Slope Condition Positive Slope (greater than, lower than, within the
specific interval);
Negative Slope (greater than, lower than, within the
specific interval)
Time Setting 10 ns to 1 s
Video Trigger
Polarity Positive, Negative
Synchrony All Lines, Line Num, Odd Field, Even Field
Standard NTSC, PAL/ECAM, 480P, 576P, 720P, 1080P, and 1080I
Pattern Trigger
Pattern Setting H, L, X, Rising Edge, Falling Edge
RS232/UART Trigger
Polarity Normal, Invert
Trigger Condition Start, Error, Check Error, Data
Baud Rate 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps,
57600 bps, 115200 bps, 230400 bps, 460800 bps,
921600 bps, 1Mbps, User
Data Bits 5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition Start, Restart, Stop, Missing ACK, Address, Data, A&D
Address Bits 7 bits, 8 bits, 10 bits
Address Range 0 to 127, o to 255, 0 to 1023
Byte Length 1 to 5
SPI Trigger
Trigger Condition CS, Timeout
Timeout Value 100 ns to 1 s
Data Bits 4 bit to 32 bit
Data H, L, X
Clock Edge Rising Edge, Falling Edge
CAN Trigger
Signal Type Rx, Tx, CAN_H, CAN_L, Differential
Trigger Condition SOF, EOF, Frame Type, Frame Error
Baud Rate 10 kb/s, 20 kb/s, 33.3 kb/s, 50 kb/s, 62.5 kb/s, 83.3

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Rigol DS4024E and is the answer not in the manual?

Rigol DS4024E Specifications

General IconGeneral
Bandwidth200 MHz
Channels4
Vertical Sensitivity1 mV/div to 10 V/div
Vertical Resolution8 bits
Max Input Voltage400 V (DC + AC peak)
Display8 inch TFT LCD (800 x 480 pixels)
Input Impedance1 MΩ
Trigger ModesEdge, Pulse, Video
Timebase Range2 ns/div to 50 s/div
InterfacesUSB, LAN
Input CouplingAC, DC, GND
Power Supply100-240 VAC, 45-440 Hz
Sample Rate2 GSa/s (Real-time)
