Chapter 16 Specifications RIGOL
DS4000E User’s Guide 16-5
kb/s, 100 kb/s, 125 kb/s, 250 kb/s, 500 kb/s, 800 kb/s, 1
Mb/s, User
Sample Point 5% to 95%
Frame Type Data, Remote, Error, OverLoad
Error Type Bit Fill, Answer Error, Check Error, Format Error, Random
Error
FlexRay Trigger
Baud Rate 2.5 Mb/s, 5 Mb/s, 10 Mb/s
Trigger Condition Frame, Symbol, Error, TSS
USB Trigger
Signal Speed Low Speed, Full Speed
Trigger condition SOP, EOP, RC, Suspend, Exit Suspend
LIN Trigger
Version 1.X, 2.X, Both
Trigger Condition Sync, Identifier, Data, ID&Data, Wakeup, Sleep, Error
ID Range 0 to 63
Data Comparison
=, ≠, <, >, ≤, ≥
Data Length 1 to 8
Data Level H, L
Baud Rate
19200 bps, 10417 bps, 9600 bps, 4800 bps, 2400 bps,
1200 bps, User
Error Type Sync, Even-Odd, Checksum
Measure
Cursor Manual mode: Voltage deviation between cursors (
△
V),
time deviation between cursors (
△T), reciprocal of △T
(Hz) (1/
△T)
Track mode: voltage and time values at the waveform
point
Auto mode: allow to display cursors during auto
measurement
Auto Measurement Maximum, Minimum, Peak-Peak Value, Top Value,
Bottom Value, Amplitude, Average, Vrms–N, Vrms-1,
Overshoot, Pre-shoot, Area, Period Area, Period,
Frequency, Rise Time, Fall Time, Positive Pulse Width,
