RIGOL Chapter 16 Specifications
16-6 DS4000E User’s Guide
Negative Pulse Width, Positive Duty Cycle, Negative
Duty Cycle, Delay A
B , Delay A B , Delay
A
B , Delay A B , Phase A B , Phase
A
B , Phase A B , Phase A B
Number of
Measurements
Displays 5 measurements at the same time.
Measurement Range Screen Region, Cursor Region
Statistic Mode Extremum, Difference
Measurement Statistic Average, Max, Min, Standard Deviation, Number of
Measurements
FontSize Normal, Large, UltraLarge
DisItem ON, OFF
Frequency Counter 6-digit hardware frequency counters
Math Operation
Waveform Operation A+B, A-B, A×B, A÷B, FFT, Digital Filter, Editable
Advanced Operation, Logic Operation
FFT Window Rectangle, Hanning, Blackman, Hamming
FFT Display Split, Full Screen
FFT Vertical Scale Vrms, dB
Logic Operation AND, OR, NOT, XOR
Math Function Intg, Diff, Lg, Ln, Exp, Abs, Square, Sqrt, Sine, Cosine,
Tangent
Decoding
Number of Buses 2
Decoding Type Parallel (standard), RS232/UART (optional), I2C
(optional), SPI (optional), CAN (optional), FlexRay
(optional), LIN (optional)
Parallel Combines the sample data of the source channel
waveforms as a parallel multi-channel bus and displays
the data as a single bus value
RS232/UART
Displays the input signal(s) of the TX source channel
or/and RX source channel as bus
