Rigol DS4024E User Manual

Chapter 16 Specifications RIGOL
DS4000E User’s Guide 16-7
I2C Displays the input signal of the SDA source channel as
bus
SPI Displays the input signal(s) of the MISO source channel
or/and MOSI source channel as bus
CAN
Displays the input signal of the source channel (Rx, Tx,
CAN_H, CAN_L, or differential) as bus
FlexRay Displays the input signal of the source channel (BP, BM,
or RX/TX) as bus
LIN Displays the input signal of the source channel of LIN as
bus
Display
Display Type 9-inch (229 mm) TFT LCD display
Display Resolution 800 horizontal×RGB×480 vertical pixel
Display Color 160,000 colors
Persistence Time Min, 50 ms, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s, 20 s,
Infinite
Display Type Dots, Vectors
Real-time Clock
Time and Date (adjustable for users)
I/O
Standard Ports Dual USB HOST, USB DEVICE, LAN, VGA Output, 10 MHz
Input/Output, Aux Output (TrigOut, Fast, PassFail, GND)
Printer
Compatibility
PictBridge
General Specifications
Probe Compensation Output
Output Voltage
[1]
About 3 V, peak-peak
Frequency
[1]
1 kHz
Power
Power Voltage 100 to 127 V, 45 to 440Hz
100 to 240 V, 45 to 65Hz

Rigol DS4024E Specifications

General

Brand	Rigol
Model	DS4024E
Category	Test Equipment
Language	English
