6 To Make Measurements RIGOL
DS6000 User’s Guide 6-3
the length cannot exceed 4 characters.
Subtraction
Subtract the waveform voltage values of signal source B from A point by point and
display the results.
Press MATH  Operate to select "A-B":
 Press Source A and Source B to select the desired channels. The channels
available are CH1, CH2, CH3 and CH4.
 Press Invert to turn the invert display of the operation results on or off.
 VERTICAL POSITION, VERTICAL SCALE, HORIZONTAL
POSITION and HORIZONTAL SCALE can also be used to adjust the
display of the operation results.
 Press Label to turn on the label modifying interface. You can refer to the
introduction in "
Channel Label" to set the label of the math operation
waveform. Note: The new label can include uppercase English letters (A to Z),
lowercase English letters (a to z), numbers (0 to 9), underlines and spaces and
the length cannot exceed 4 characters.
Multiplication
Multiply the waveform voltage values of signal source A and B point by point and
display the results.
Press MATH  Operate to select "AxB":
 Press Source A and Source B to select the desired channels. The channels
available are CH1, CH2, CH3 and CH4.
 Press Invert to turn the invert display of the operation results on or off.
 VERTICAL POSITION, VERTICAL SCALE, HORIZONTAL
POSITION and HORIZONTAL SCALE can also be used to adjust the
display of the operation results.
 Press Label to turn on the label modifying interface. You can refer to the
introduction in "
Channel Label" to set the label of the math operation
waveform. Note: The new label can include uppercase English letters (A to Z),
