6 To Make Measurements RIGOL
DS6000 User’s Guide 6-5
Division
Divide the waveform voltage values of signal source A by B point by point and display
the results. It can be used to analyze the multiple relationships of waveforms in two
channels. Note that when the voltage value of the waveform of signal source B is 0,
the result of the division is treated as 0.
Press MATH  Operate to select "A÷B":
 Press Source A and Source B to select the desired channels. The channels
available are CH1, CH2, CH3 and CH4.
 Press Invert to turn the invert display of the operation results on or off.
 VERTICAL POSITION, VERTICAL SCALE, HORIZONTAL
POSITION and HORIZONTAL SCALE can also be used to adjust the
display of the operation results.
 Press Label to turn on the label modifying interface. You can refer to the
introduction in "
Channel Label" to set the label of the math operation
waveform. Note: The new label can include uppercase English letters (A to Z),
lowercase English letters (a to z), numbers (0 to 9), underlines and spaces and
the length cannot exceed 4 characters.
