RIGOL 10 Waveform Recording
10-10 DS6000 User’s Guide
is an error frame. A frame can be recognize as an error one if the (relative)
difference between the frame and the template is equal to or larger than
the threshold currently set.
Analysis Based on Trace
Press Analyze and select "Trace". Then, set the template used in analysis based on
trace through the method below.
1. Trace
Press Trace to select the creation method of analysis template.
 Current Frame: select the current frame as the analysis template.
 Average: select the average of the current data frame as the analysis
template.
2. Setup Template
Press Template to configure the template immediately. After the analysis starts,
the oscilloscope compares each frame with the template to compute the
difference and determines whether error frame exists by comparing the
difference with the threshold currently set.
3. Template Display
Press Template to turn on or off the display of the template.
