RIGOL 6 To Make Measurements
6-22 DS6000 User’s Guide
n
x
RMS
n
i
i
∑
=
=
1
2
, where,
i
x
is the measurement result of the i
th
point being
measured,
n
is the number of points being measured.
10. Overshoot: the ratio of the difference of the maximum value and top value of
the waveform to the amplitude value.
11. Preshoot: the ratio of the difference of the minimum value and base value of
the waveform to the amplitude value.
Area Parameters
1. Area: the area of the whole waveform or the waveform in the gating area and
the unit is voltage-second. The area measured above the zero reference
(namely the vertical offset) is positive and the area measured below the zero
reference is negative. The area measured is the algebraic sum of the area of the
whole waveform within the screen.
2. Period Area: the area of a single period of waveform on the screen or in the
gating area and the unit is voltage-second. The area above the zero reference
(namely the vertical offset) is positive and the area below the zero reference is
negative. The area measured is the algeraic sum of the area of the whole period
waveform.
