If needed, please refer to the following steps to modify track cursor measurement
parameters.
1. Select Track Axises
Press AXIS to select "X" or "Y" to be the current track axis. The default axis is
"Y".
 X: You can adjust the vertical position of Y cursor, and X cursor will
automatically track the time or frequency of the wave of the corresponding
measurement source at Y cursor. You can also press Type to select the
track type of X cursor.
 Y: You can adjust the horizontal position of X cursor, and Y cursor will
automatically track the vertical amplitude of the wave of the corresponding
measurement source at X cursor.
2. Select Measurement Source
Press Cursor A to select the waveform in analog channels (CH1-CH4) or math
operation results (MATH) as the measurement source of cursor A (only channels
enabled are available). You can also select "None", namely do not use cursor A.
Press Cursor B to select the waveform in analog channels (CH1-CH4) or math
operation results (MATH) as the measurement source of cursor B (only channels
enabled are available). You can also select "None", namely do not use cursor B.
3. Adjust Cursor Position (Note: On the same menu page, you can also
press
continuously to switch the current cursor.)
When AXIS is set to "X",
 Adjust cursor A: press CursorA and use to adjust the vertical position
of cursor A. During the adjustment, the measurement result will change
accordingly. The adjustable range is limited within the screen.
 Adjust cursor B: press CursorB and use to adjust the vertical position
of cursor B. During the adjustment, the measurement result will change
accordingly. The adjustable range is limited within the screen.
 Adjust cursor A and B at the same time: press CursorAB and use to
adjust the vertical positions of cursor A and B at the same time. During the
adjustment, the measurement results will change accordingly. The
adjustable range is limited within the screen.
Note: The cursor will track the marked point (namely moves left and right
