RIGOL

XVI DS6000 User’s Guide

Table of Contents

Guaranty and Declaration3
Safety Requirement4
- General Safety Summary4
- Safety Notices and Symbols7
- Allgemeine Sicherheits Informationen8
- Sicherheits Begriffe und Symbole11
- Measurement Category12
- Ventilation Requirement13
- Working Environment14
  - Pollution Degree15
  - Pollution Degree Definitions15
- Care and Cleaning16
- Environmental Considerations17
DS6000 Series Overview19
Document Overview21
- Table of Contents24
1 Quick Start31
- General Inspection32
- Appearance and Dimensions33
- Preparations for Use34
- Front Panel Overview45
- Rear Panel Overview47
- Front Panel Function Overview49
- User Interface57
- Trigger Type59
- Security Lock63
- Desk Mount Instrument Arm64
- Built-In Help System65
2 To Set the Vertical System67
- To Enable the Channel68
- Channel Coupling69
- Bandwidth Limit70
- Probe71
- Input Impedance75
- Waveform Invert75
- Vertical Scale76
- Vertical Position77
- Vertical Expansion78
- Amplitude Unit78
- Channel Label79
- Delay Calibration80
3 To Set the Horizontal System81
- Delayed Sweep82
- Time Base Mode84
- Horizontal Scale89
- Horizontal Position89
- Horizontal Reference91
4 To Set the Sample System93
- Acquisition Mode94
- Sample Mode97
  - Real-Time Sample97
  - Equivalent Sample97
- Sample Rate98
- Memory Depth100
- Anti-Aliasing101
5 To Trigger the Oscilloscope103
- Trigger Source104
- Trigger Mode105
- Trigger Coupling107
- Trigger Holdoff108
- Trigger Type109
- Trigger Output Connector135
6 To Make Measurements137
- Math Operation138
- Auto Measurement150
- Cursor Measurement165
7 Protocol Decoding179
- Parallel Decoding180
- RS232 Decoding (Option)183
- I2C Decoding (Option)188
- SPI Decoding (Option)191
- CAN Decoding (Option)195
- Flexray Decoding (Option)199
8 Reference Waveform203
- To Enable REF Function204
- To Set the Color205
- To Select REF Source206
- To Save to Internal Memory206
- To Adjust REF Waveform Display206
- To Export to Internal or External Memory207
- To Import from Internal or External Memory207
9 Pass/Fail Test209
- To Enable Pass/Fail Test Function210
- To Select Source211
- Mask Range211
- Test and Output212
- To Save the Test Mask213
- To Load the Test Mask213
10 Waveform Recording215
- Record Constant on218
- Waveform Playback219
- Waveform Analysis221
  - Analysis Based on Trace224
  - Analysis Based on Pass/Fail Mask225
11 Display Control227
- To Select the Display Type228
- To Set the Persistence Time229
- To Set the Waveform Brightness231
- To Set the Screen Grid231
- To Set the Grid Brightness231
- To Set the Menu Display231
12 Store and Recall233
- Storage System234
- Storage Type235
- Internal Store and Recall237
- External Store and Recall240
- Disk Management242
- Factory249
13 System Function Setting257
- Remote Interface Configuration258
- System-Related263
- To Print the Waveform271
14 Remote Control275
- Remote Control Via USB276
- Remote Control Via LAN280
- Remote Control Via GPIB282
15 Troubleshooting285
16 Specifications287
- General Specifications294
- Calibration Interval294
17 Appendix295
- Appendix A: Accessories and Options295
- Appendix B: Warranty296
Index297
