RIGOL 7 Protocol Decoding

7-12 DS6000 User’s Guide

5. Error Expressions during Decoding

In I2C bus, the front part of each frame of data contains the address information

and blue patches are used to represent address ID. In the ID, "Write" is used to

represent writing address and "Read" is used to represent reading address.

When the ACK (ACKnowledge Character) is not met, the red error marks as

shown in the figure below will be displayed.

ACK=1
