Rigol DS6104 User Manual

RIGOL 16 Specifications
16-6 DS6000 User’s Guide
Measure
Cursor
Manual
Mode
Voltage Deviation between Cursors (
△
V)
Time Deviation between Cursors (
△
T)
Reciprocal of
△
T (Hz) (1/
△
T)
Track Mode Voltage and Time Values of the Waveform
Point
Auto Mode Allow to display cursors during auto
measurement
Auto Measurement Maximum, Minimum, Peak-Peak Value, Top Value, Base
Value, Amplitude, Average, Vrms–N, Vrms-1, Overshoot,
Pre-shoot, Area, Period Area, Frequency, Period, Rise
Time, Fall Time, Positive Pulse Width, Negative Pulse
Width, Positive Duty Cycle, Negative Duty Cycle, Delay
A
B , Delay A B , Delay A B , Delay A B ,
Phase A
B , Phase A B , Phase A B , Phase
A
B
Number of
Measurements
Display 5 measurements at the same time.
Measurement Range Screen, Cursor
Statistic Mode Extremum, Difference
Measurement Statistic Average, Max, Min, Standard Deviation, Number of
Measurements
Frequency Counter Hardware 6 bits frequency counter
(channels available: DS606x, CH1/CH2; DS610x,
CH1/CH2/CH3/CH4)
