RIGOL 2 To Set the Vertical System
2-8 DS6000 User’s Guide
When a Tek probe is inserted, the following menus are added in addition to the
Probe Type and Ratio menus.
1. Model
Press Model and use to select the probe model corresponding to the probe
currently connected. The probe models available include P6205, P6241, P6243,
P6245, P6246, P6247, P6248, P6249, P6250, P6251, P5205, P5210, P670X,
P671X and TCP202.
2. Front-End
Front-End displays the current probe front end.
Note: When the probe currently connected is P670X, P671X or TCP202, this
menu is not available.
In addition, the oscilloscope supports the probe calibration and bias voltage
adjustment of some Tek probes, including P6241, P6245, P6246, P6247, P6248,
P6249, P6250 and P6251. For these probes, Probe-Cal and Bias Voltage are
provided in the probe operation menu.
3. Probe-Cal
Press Probe-Cal and ground the probe input terminal according to the probe
calibration prompt message. Press OK and the oscilloscope starts calibrating the
probe.
4. Bias Voltage
Press Bias Voltage and use to adjust the bias voltage. The adjustable
range is related to the probe model and probe ratio (only for models that
support multiple probe ratios). For the details, please refer to the technical
specifications of the corresponding probe.
