Rigol MSO7000 Series

Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-93
:MATH<n> Commands
The :MATH<n> commands are used to set various math operation function of the waveform between
channels.
Note:
 The math operations include the following types:
arithmetic operations: A+B, A-B, A× B, A/B
spectrum operation: FFT
Logic operation: A&&B, A||B, A^B, !A
function operation: Intg, Diff, Sqrt, Lg, Ln, Exp, Abs, AX+B
digital filter: Low Pass Filter, High Pass Filter, Band Pass Filter, Band Stop Filter
 For the logic operation, the waveform data involved in the operation and the preset threshold are
compared with each other, and then transferred to 0 or 1. Therefore, the operation results are only
reduced to 0 and 1.
Command List:
 :MATH<n>:DISPlay
 :MATH<n>:OPERator
 :MATH<n>:SOURce1
 :MATH<n>:SOURce2
 :MATH<n>:LSOUrce1
 :MATH<n>:LSOUrce2
 :MATH<n>:SCALe
 :MATH<n>:OFFSet
 :MATH<n>:INVert
 :MATH<n>:RESet
 :MATH<n>:FFT:SOURce
 :MATH<n>:FFT:WINDow
 :MATH<n>:FFT:SPLit
 :MATH<n>:FFT:UNIT
 :MATH<n>:FFT:SCALe
 :MATH<n>:FFT:OFFSet
 :MATH<n>:FFT:HSCale
 :MATH<n>:FFT:HCENter
 :MATH<n>:FFT:FREQuency:STARt
 :MATH<n>:FFT:FREQuency:END
 :MATH<n>:FFT:SEARch:ENABle
 :MATH<n>:FFT:SEARch:NUM
 :MATH<n>:FFT:SEARch:THReshold
 :MATH<n>:FFT:SEARch:EXCursion
 :MATH<n>:FFT:SEARch:ORDer
