Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-57
:CURSor:TRACk
Command List:
 :CURSor:TRACk:SOURce1
 :CURSor:TRACk:SOURce2
 :CURSor:TRACk:CAX
 :CURSor:TRACk:CBX
 :CURSor:TRACk:CAY?
 :CURSor:TRACk:CBY?
 :CURSor:TRACk:AXValue?
 :CURSor:TRACk:AYValue?
 :CURSor:TRACk:BXValue?
 :CURSor:TRACk:BYValue?
 :CURSor:TRACk:XDELta?
 :CURSor:TRACk:YDELta?
 :CURSor:TRACk:IXDELTA?
:CURSor:TRACk:SOURce1
Syntax
:CURSor:TRACk:SOURce1 <source>
:CURSor:TRACk:SOURce1?
Description
Sets or queries the channel source of Cursor A in the track mode of cursor measurement.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4|
MATH1|MATH2|MATH3|MATH4|NONE}
CHANnel1
Remarks
Only the currently enabled channel can be selected as the channel source.
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, MATH1, MATH2, MATH3, MATH4, or
NONE.
Example
:CURSor:TRACk:SOURce1 CHANnel2 /*Sets the channel source to CH2.*/
:CURSor:TRACk:SOURce1? /*The query returns CHAN2.*/
