Rigol MSO7000 Series User Programming Manual

Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-113
:MEASure:STATistic:DISPlay
Syntax
:MEASure:STATistic:DISPlay <bool>
:MEASure:STATistic:DISPlay?
Description
Enables or disables the statistical function; or queries the status of the statistical
function.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Remarks
When the statistical function is enabled, the instrument makes statistics of the
measurement results for at most 10 measurement items that are turned on last time
and displays the statistical results.
Return
Format
The query returns 1 or 0.
Example
:MEASure:STATistic:DISPlay ON /*Enables the statistical function.*/
:MEASure:STATistic:DISPlay? /*The query returns 1.*/
:MEASure:STATistic:RESet
Syntax
:MEASure:STATistic:RESet
Description
Clears the history statistics data and makes statistics again.
:MEASure:STATistic:ITEM
Syntax
:MEASure:STATistic:ITEM <item>[,<src>[,<src>]]
:MEASure:STATistic:ITEM? <type>,<item>[,<src>[,<src>]]
Description
Enables the statistical function of any waveform parameter of the specified source, or
queries the statistical results of any waveform parameter of the specified source.
Parameter
Name
Type
Range
Default
<item>
Discrete
{VMAX|VMIN|VPP|VTOP|VBASe|VAMP|VA
VG|VRMS|OVERshoot|PREShoot|MARea|
MPARea|PERiod|FREQuency|RTIMe|FTIM
e|PWIDth|NWIDth|PDUTy|NDUTy|TVMax|
TVMin|PSLewrate|NSLewrate|VUPPer|VMI
D|VLOWer|VARiance|PVRMs|PPULses|NP
ULses|PEDGes|NEDGes|RRDelay|RFDelay
|FRDelay|FFDelay|RRPHase|RFPHase|FRP
Hase|FFPHase}
——
<src>
Discrete
Refer to Remarks
——
<type>
Discrete
{MAXimum|MINimum|CURRent|AVERages
|DEViation}
——
Remarks
 The parameter [,<src>[,<src>]] is used to set the source of the parameter
under measurement.
 If the parameter <item> is set to PERiod, FREQuency, PWIDth, NWIDth, PDUTy,
NDUTy, RRDelay, RFDely, FFDelay, RRPHas, RFPHase, FRPHase, or FFPHase, the
range of the parameter <src> is any one of the values in
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D12|D13|D14|D15|CHANnel1|C
