Rigol MSO7000 Series

RIGOL Chapter 2 Command System
2-112 MSO7000/DS7000 Programming Guide
:MEASure:SETup:PSB
Syntax
:MEASure:SETup:PSB <source>
:MEASure:SETup:PSB?
Description
Sets or queries Source B in the phase or delay measurement.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D
12|D13|D14|D15|CHANnel1|CHANnel2|CHANnel
3|CHANnel4|MATH1|MATH2|MATH3|MATH4}
CHANnel2
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, MATH1, MATH2, MATH3, or MATH4.
Example
:MEASure:SETup:PSB CHANnel2 /*Sets Source B of the phase measurement to CH2.*/
:MEASure:SETup:PSB? /*The query returns CHAN2.*/
:MEASure:SETup:DSA
Syntax
:MEASure:SETup:DSA <source>
:MEASure:SETup:DSA?
Description
Sets or queries Source A in the phase or delay measurement.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D
12|D13|D14|D15|CHANnel1|CHANnel2|CHANnel
3|CHANnel4|MATH1|MATH2|MATH3|MATH4}
CHANnel1
Remarks
Return
Format
This command has the same function as the :MEASure:SETup:PSA command.
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, MATH1, MATH2, MATH3, or MATH4.
Example
:MEASure:SETup:DSA CHANnel1 /*Sets Source A of the delay measurement to CH1.*/
:MEASure:SETup:DSA? /*The query returns CHAN1.*/
:MEASure:SETup:DSB
Syntax
:MEASure:SETup:DSB <source>
:MEASure:SETup:DSB?
Description
Sets or queries Source B in the phase or delay measurement.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11|D
12|D13|D14|D15|CHANnel1|CHANnel2|CHANnel
3|CHANnel4|MATH1|MATH2|MATH3|MATH4}
CHANnel1
Remarks
Return
Format
This command has the same function as the :MEASure:SETup:PSB command.
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, MATH1, MATH2, MATH3, or MATH4.
Example
:MEASure:SETup:DSB CHANnel2 /*Sets Source B of the delay measurement to CH2.*/
:MEASure:SETup:DSB? /*The query returns CHAN2.*/
