Rigol MSO7000 Series User Programming Manual

Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-95
:MATH<n>:SOURce1
Syntax
:MATH<n>:SOURce1 <src>
:MATH<n>:SOURce1?
Description
Sets or queries the source or Source A of arithmetic operation and function operation.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Remarks
 For arithmetic operation, this command is used to set Source A.
 For function operation, use this command only to set the source.
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MATH1:SOURce1 CHANnel3 /*Sets Source A of the arithmetic operation to CH3.*/
:MATH1:SOURce1? /*The query returns CHAN3.*/
:MATH<n>:SOURce2
Syntax
:MATH<n>:SOURce2 <src>
:MATH<n>:SOURce2?
Description
Sets or queries Source B of arithmetic operation.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<src>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Remarks
This command is only available for arithmetic operation (containing two sources).
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MATH1:SOURce2 CHANnel3 /*Sets Source B of the arithmetic operation to CH3.*/
:MATH1:SOURce2? /*The query returns CHAN3.*/
:MATH<n>:LSOUrce1
Syntax
:MATH<n>:LSOUrce1 <src>
:MATH<n>:LSOUrce1?
Description
Sets or queries Source A of the logic operation.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<src>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Remarks
The logic operations include A&&B, A||B, A^B, and !A.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.

Rigol MSO7000 Series Specifications

General

Memory Depth	Up to 500 Mpts
Operating Temperature	0 °C to +50 °C
Channels	4 analog + 16 digital
Display	10.1 inch capacitive touchscreen
Waveform Capture Rate	Up to 600, 000 wfms/s
Vertical Resolution	8 bits
Maximum Input Voltage	400 V (DC + AC peak)
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Window, Runt, Setup/Hold, Delay, Nth Edge
Protocol Decoding	RS232/UART, I2C, SPI, CAN, LIN, FlexRay, I2S, MIL-STD-1553, ARINC429
Interfaces	USB, LAN, HDMI
