Rigol MSO7000 Series User Programming Manual

Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-197
:TRIGger:NEDGe:IDLE
Syntax
:TRIGger:NEDGe:IDLE <time>
:TRIGger:NEDGe:IDLE?
Description
Sets or queries the idle time of the Nth Edge trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<time>
Real
16 ns to 1 s
1 μs
Return
Format
The query returns the idle time in scientific notation.
Example
:TRIGger:NEDGe:IDLE 0.002 /*Sets the idle time to 2 ms.*/
:TRIGger:NEDGe:IDLE? /*The query returns 2.000000E-3.*/
:TRIGger:NEDGe:EDGE
Syntax
:TRIGger:NEDGe:EDGE <edge>
:TRIGger:NEDGe:EDGE?
Description
Sets or queries the number of edges of the Nth Edge trigger.
Parameter
Name
Type
Range
Default
<edge>
Integer
1 to 65535
2
Return
Format
The query returns an integer ranging from 1 to 65535.
Example
:TRIGger:NEDGe:EDGE 20 /*Sets the number of edges to 20.*/
:TRIGger:NEDGe:EDGE? /*The query returns 20.*/
:TRIGger:NEDGe:LEVel
Syntax
:TRIGger:NEDGe:LEVel <level>
:TRIGger:NEDGe:LEVel?
Description
Sets or queries the trigger level of the Nth Edge trigger. The unit is the same as that
of current amplitude.
Parameter
Name
Type
Range
Default
<level>
Real
(-5 × VerticalScale - OFFSet) to
(5 × VerticalScale - OFFSet)
0 V
Remarks
For VerticalScale, refer to the :CHANnel<n>:SCALe command; for OFFSet, refer to
the :CHANnel<n>:OFFSet command.
Return
Format
The query returns the trigger level in scientific notation.
Example
:TRIGger:NEDGe:LEVel 0.16 /*Sets the trigger level to 160 mV.*/
:TRIGger:NEDGe:LEVel? /*The query returns 1.600000E-1.*/
