6
Controls and Functions
Menu key
When this key is pressed, the menu screen 1/5 appears on the display. Pressing
the key again switches the display back to the original condition.
Menu pages are switched with the Page
keys to the right of the
key.
A/C/FLAT key
Sets frequency weighting to A, C or FLAT.
Fast/Slow key
Sets the time weighting to Fast or Slow.
Level Range , keys
Select the level range for the measurement.
The following six settings are available:
20 to 80, 20 to 90, 20 to 100, 20 to 110, 30 to 120, 40 to 130
With the filter function activated, the following seven settings are available:
10 to 70, 20 to 80, 30 to 90, 40 to 100, 50 to 110, 60 to 120, 70 to 130
Recall key
Serves to recall data stored in the memory of the unit.
Recall Data , keys
When the display shows the measurement screen and the manual store mode
is selected, these keys select the data number in which to store data next.
When the display shows data from memory, the keys select the data number to
be displayed. When the filter function is active, this key serves to switch filter
frequencies.
Light key
This key activates the backlight for easier viewing of the display in low-light
conditions. To turn the backlight off, press the key once more.
When the automatic light out function was selected from the menu, the light
will turn itself off automatically after 5 minutes.
