10
Preparations
Power Supply
The unit can be powered by four IEC R6P (size AA) batteries (alkaline or
manganese) or by the specified optional AC adapter.
It is possible to use size AA rechargeable batteries, but a separate recharger
must be provided for such batteries, since the unit is not designed to recharge
batteries.
Note
When the AC adapter is connected, the unit will be
powered from the adapter, also when batteries are
inserted. (The AC adapter has priority.)
In case of a power failure or other interruption of AC
power, the unit will automatically switch to battery
power and continue to operate.
Inserting the batteries
1. Lightly press the cover of the battery compartment and slide it to the
right.
2. Insert the four IEC R6P batteries, paying attention to the polarity as
indicated in the compartment.
3. Replace the cover.
L i g h t l y p r e s s h e r e a n d
s l i d e t o t h e r i g h t
I E C R 6 P
( s i z e A A )
b a t t e r y
