Rion NL-21 - Microphone Extension Cables (EC-04 Series)

15
Preparations
Important
With long extension cables, the cable capaci-
tance restricts the upper measurement fre-
quency and measurement level. For details,
please refer to the Technical Notes.
Important
Be sure to turn the unit off before inserting and
removing the card from the unit.
E C - 0 4
E C - 0 4 A
E C - 0 4 B
E C - 0 4 C
E C - 0 4 D
E C - 0 4 E
2 m
5 m
1 0 m
3 0 m ( r e e l ) + 5 m ( c o n n c e t i o n c a b l e )
M o d e l L e n g t h
M o d e l
L e n g t h
5 0 m ( r e e l ) + 5 m ( c o n n e c t i o n c a b l e )
1 0 0 m ( r e e l ) + 5 m ( c o n n e c t i o n c a b l e )
E x t e n s i o n c a b l e E C - 0 4 s e r i e s
Microphone Extension Cables (EC-04 series)
Turn power to the unit off before separating the microphone from the main
unit.
To reduce measurement deviations due to refraction effects and the acoustic
influence of the operator, the microphone can be detached from the unit and
connected via an extension cable. Optional cables are listed in the table below.
It is also possible to connect several cables in series.
