16
Preparations
Important (NL-31 only)
Never remove the microphone grid, because
this can lead to damage.
Before using the microphone and before putting
it away, always check that the microphone grid
has not become loose. If this has happened,
refasten the microphone grid firmly and then
use or store the microphone.
Important
Never separate the microphone and preampli-
fier, because this can lead to damage.
1. Loosen the preamplifier fastening screw and remove the preamplifier
from the main unit.
T r i p o d
M i c r o p h o n e h o l d e r
M i c r o p h o n e
C o n n e c t o r
M i c r o p h o n e
e x t e n s i o n c a b l e
2. Connect the extension cable to the preamplifier and to the main unit
and fasten the connectors with the fastening screw.
3. When mounting the microphone on a tripod, first fasten the microphone
holder (supplied with the extension cable) to the tripod. Then insert
the extension cable connector into the microphone holder.
