73
Measurement
5. To use the data exclusion (back-erase) function, please refer to page 77.
Note
In addition to the regular pause function it is also
possible to exclude (back-erase) data from the im-
mediately preceding 5 seconds. However, when L
Atm5
is selected, the back-erase function cannot be used.
1 5
< S y s t e m >
M e a s . t i m e : 1 0 m i n
B a c k E r a s e : O f f
C a l M o d e : I n t e r n a l
F i l t e r : O f f
M e a s u r e m e n t t i m e
( a c t u a l t i m e )
M e n u s c r e e n 1 / 5
4. Use the Page Up/Down keys to display the menu screen 1/5.
Use the and keys to move the cursor to the "Meas. time" item,
and use the and keys to select the measurement time.
Manual → 10 sec → 1 min → 5 min → 10 min → 15 min → 30 min
→ 1 hour → 8 hours → 24 hours → Manual → ...
