Risco Agility Software Manual

 AgilityConfigurationSoftwareManual
Page 26
2. Clickonthe buttontoexportthefile.
3.3.5 Connect/Disconnect
ToestablishcommunicationwiththeAgility,fromthemainmenuselect
Communication>Connect.

Todisconnectcommunication withtheAgility,fromth e mainmenuselect
Communication>Disconnect.
3.3.6 Configuration
Thisdialogboxenablesyoutodefinetheparametersofsettingupthecommunication
betweentheConfigurationSoftwareandtheAgilitythroughmodem,GSM,TCP/IPor
directcable.YoursystemshouldbesetcorrectlyinordertoconnecttotheAgility.Once
defined,theseconfigurationswillbeusedbyyourcomputer,
whentryingtoestablish
communicationtoanyAgilitypanel.
Local communication
¾Todefinelocalcommunication,setuptheparametersasfollows:
1. SelecttheDirectcommu nication channelfromthedropdownlistandfillinthe
parametersasfollows:
Port:Selecttherelevantport
BaudRate:Setto38400(defaultvalue)
DataBits:Setto8(defaultvalue)
Parity:Setto None(defaultvalue)
StopBit:Setto2(defaultvalue)
Handshake:SettoNone(defaultvalue)

Figure17:Communicationdialogbox‐Localconnectionsetup
2. ClickOK.
