Rish Master 3430 User Manual

Pulse output Option ( 1 or 2 Relay ) :
1NO + 1NC
Relay
240VDC , 5Amp.
Switching Voltage & CurrentSwitching Voltage & Current
1 per Wh (up to 3600W),
1 per kWh (up to 3600kW),
1 per MWh (above 3600 kW)
Default Pulse rate Divisor
Pulse rate Divisors
Programmable on site
1 per 10Wh (up to 3600W),
1 per 10kWh (up to 3600kW),
1 per 10MWh (above 3600 kW)
10
1 per 100Wh (up to 3600W),
1 per 100kWh (up to 3600kW),
1 per 100MWh (above 3600 kW)
100
1 per 1000Wh (up to 3600W),
1 per 1000kWh (up to 3600kW),
1 per 1000MWh (above 3600 kW)
1000
60ms , 100ms or 200ms
Pulse Duration
Note : Above conditions are also applicable for Reactive & Apparent Energy .
ModBus ( RS 485 ) Option :
ModBus ( RS 485 )
Protocol
19200 , 9600 , 4800 or 2400
Baud Rate
( Programmable )
Odd or Even, with 1 stop bit,
Parity
Or None with 1 or 2 stop bits
Note : Pulse rate divisor is set to 1, when Energy on Rs485 is set to kWh or MWh.
Analog Output Option :
0 ... 1mA dc into 0 - 2 kohm
Linear
Uni-directional, internally powered .
4 ... 20mA dc into 0 - 500 ohm
Uni-directional, internally powered.
76
