Rish Master 3430 User Manual

Low current noise cutoff Confirmation.
Pressing “ Up” key set displayed value and
Advance to the Rs485 address selection.
(See section 3.2.9)
pressing the “ Down” key will re-enter the “Low
current Noise cutoff Edit” mode.
3.2.9 RS 485 Address Selection:
VRY
KVAr
Sys
V
KW
VBR
Angle
Max
x1000
KVArh
x1000
IN
Ph R
P.F.
KWh
Ph B
A
VYB
KVA
Min
x1000
Hz
KVAh
Ph Y
%THD
x1000
Hz
KVAh
Ph Y
%THD
This screen applies to the RS 485 output only.
This screen allows the user to set RS485
address for instruments
Enter Address, prompt for first digit.
(* Denotes that decimal point will be flashing).
Press the “ Down” key to scroll the value of the first digit
Press the “ Up” key to advance to next digit.
The range of allowable address is 1 to 247 .
VYB
VRY
KVAr
Sys
V
A
KVA
Min
KW
VBR
Angle
Max
x1000
KVArh
x1000
x1000
IN
Ph R
Hz
KVAh
Ph Y
P.F.
KWh
Ph B
KAh
%THD
23
