2: System Description
20
The Rear of the Computer
These features can be identified at the rear of the computer:
Mains power
connector
System board
I/O panel
Expansion
Slots
Note:
Not all connectors are shown here. I/O connectors may appear in any position in
the I/O panel and additional connectors may appear in any of the expansion slots
according to the model.
Refer to page 76 for further details about the rear panel
connectors.
Fan
The grill on the rear panel is the outlet for the cooling fan.
Caution:
Do not obstruct the PSU outlet, or this may lead to overheating.
