3: Fitting Hardware Options
53
3. Keeping the DIMM at this angle, slide it between the slots at
each end of the DIMM socket it horizontal and at a 90° to the
socket. Press the DIMM firmly into the socket, the retaining
clips will ‘click’ into place , securing the DIMM at each end of
the socket. Make sure that both of these clips are in the vertical
position.
4. Replace the cover of the computer (see page 44) and reconnect
your system as shown on the “Setting Up Your New Computer”
card.
5. When you switch on your computer, the system automatically
detects the extra memory and updates the CMOS RAM.
On some models you may need to enter the Setup program to
confirm the CMOS RAM, in this case the following message is
displayed:
RUN SETUP UTILITY
Press <F1> to RESUME
Press <F1> to run Setup. Enter your password, if the system
prompts you to do so (for default password see page 80). At the
main menu, save the changes. The system will reboot.
Check the memory test during boot-up to see that the correct
amount of memory has been detected and that your upgrade is
working correctly.
6. Replace the cover of the computer (see page 44) and reconnect
your system as shown on the “Setting Up Your New Computer”
card.
