1 Introduction
Manual TME400-VMF · EN02 · 2018 September 6th
23
ANSI 300
PN 64
ANSI 600
DN
d1
d2
d3
d1
d2
d3
d1
d2
50
2"
51
69.9
85.9
54
66
84
51
69.9
85.9
80
3"
81
101.6
120.7
86
95
119
81
101.6
120.7
100
4"
106.4
127.0
149.4
108
120
144
106.4
120.7
149.4
150
6"
157.2
182.6
209.6
162
174
200
157.2
174.8
209.6
200
8"
215.9
233.4
263.7
213
225
257
215.9
225.6
263.7
250
10"
268.3
287.3
317.5
267
279
315
268.3
274.6
317.5
300
12"
317.5
339.9
374.7
318
330
366
317.5
327.2
374.7
400
16"
400
422.4
463.6
414
426
466
400
412.8
463.6
500
20"
500
525.5
577.9
518
530
574
500
520.7
577.9
600
24"
603.3
628.7
685.8
618
630
674
603.3
628.7
685.8
Note
When flange seals which protrude into the pipeline are used for turbine me-
ters, the measuring accuracy can be influenced negatively. Ensure that the
flange seals do not protrude beyond the seal surfaces into the pipeline.
Danger
Gas escape due to incorrect seal
If incorrect flange seals are used for the assembly of turbines, an explosive
gas mixture can form due to leaks.
Danger of poisoning and explosion!
In addition, the stress on the flange is increased to an impermissible level
when tightening the thread bolts.
Ensure secure fastening/attachment of the TME400 during assembly in order
to avoid crushing. Ensure that you keep your fingers (or other body parts)
away from these openings and gaps when pulling the flanges together.
