RMG TME400-VMF User Manual

1 Introduction
MANUAL TME400-VCF · EN08 · July, 01
st
2021
26
ANSI 300 / ANSI 600
PN 64
DN
d1
d2
d1
d2
50
2"
69.8
88.9
65
87
80
3"
98.4
123.8
95
121
100
4"
123.8
154.0
118
144
150
6"
177.8
212.7
170
204
200
8"
228.6
266.7
220
258
250
10"
282.6
320.7
270
315
300
12"
339.7
377.8
320
365
400
16"
422.3
466.7
426
474
500
20"
530.2
581.0
530
578
600
24“
631.8
682.6
630
680
Spiral seals (EN 12560-2 with centering ring)
ANSI 300
PN 64
ANSI 600
DN
d1
d2
d3
d1
d2
d3
d1
d2
50
2"
51
69.9
85.9
54
66
84
51
69.9
85.9
80
3"
81
101.6
120.7
86
95
119
81
101.6
120.7
100
4"
106,4
127.0
149.4
108
120
144
106,4
120.7
149.4
150
6"
157,2
182.6
209.6
162
174
200
157,2
174.8
209.6
200
8"
215,9
233.4
263.7
213
225
257
215,9
225.6
263.7
250
10"
268,3
287.3
317.5
267
279
315
268,3
274.6
317.5
300
12"
317,5
339.9
374.7
318
330
366
317,5
327.2
374.7
400
16"
400
422.4
463.6
414
426
466
400
412.8
463.6
500
20"
500
525.5
577.9
518
530
574
500
520.7
577.9
600
24"
603,3
628.7
685.8
618
630
674
603.3
628.7
685.8
