RMG TME400-VMF User Manual

1 Introduction
MANUAL TME400-VCF · EN08 · July, 01
st
2021
32
1.4.2.6.
Technical guideline G13
The installation conditions for new systems according to TRG G13 and the facilitated
installation conditions for RMG turbine meters are compared in the table below.
Type of up-
stream per-
tubation
Installation
conditions
according to
TR G13
Installation con-
ditions for RMG
type TME400
meters
Comments
none
Inlet  5 DN
Outlet  2 DN
Inlet  2 DN
Outlet  2 DN
The outlet pipe can also be designed as
a bend.
Inlet  10 DN
Pertubation upstream from this inlet
pipe does not have to be factored in
when the requirements for an alternat-
ing and pulsing flow are fulfilled.
Bend
Inlet  5 DN
Inlet  2 DN
Bends in 2
planes
Inlet  5 DN
plus 2 perforated
plate straighteners
or a bend straight-
ener
Inlet  2 DN
Gas pressure
regulating de-
vice with an at-
tenuator
Inlet  5 DN
Inlet  2 DN
plus 1 perforated
plate straightener
Gas pressure
regulating de-
vice without an
attenuator
Inlet  5 DN
plus 2 perforated
plate straighteners
Inlet  2 DN
plus 1 perforated
plate straightener
Diffuser
Inlet  5 DN
plus 1 perforated
plate straighteners
Inlet  2 DN
Diffuser with
swirling flow
Inlet  5 DN
plus 2 perforated
plate straighteners
Inlet  2 DN
