4 Operation
Manual TME400-VMF · EN02 · 2018 September 6th
58
B09
Maximum time > Qug +
Indicates the maximum time until the flow rate (e.g. on start-up )
reaches the measuring range (Qmin) after reaching the lower meas-
uring limit (Qug). The flow rate measurement applies as defective
during this time, but no error message is generated.
Coor-
dinate
Name
Modbus
register
Modbus
access
Protec-
tion
Data
type
Min.
Max.
Default
Unit
B02
Operating flow rate
320
R
A
float
-
-
*
m3/h
B03
Frequency
322
R
A
float
-
-
*
Hz
B05
Min. flow rate
521
W
E
float
*
*
0.0
m3/h
B06
Max. flow rate
523
W
E
float
*
*
1000.0
m3/h
B10
Coefficient A-2
530
W
E
float
*
*
0
Am2
B11
Coefficient A-1
532
W
E
float
*
*
0
Am1
B12
Coefficient A0
534
W
E
float
*
*
0
A0
B13
Coefficient A1
536
W
E
float
*
*
10000
A1
B14
Coefficient A2
538
W
E
float
*
*
0
A2
B15
Max. operating point de-
viation
540
W
E
float
0.0
100.0
2.0
kkp
B08
Leak flow volume limit
527
W
E
float
*
*
*
m3/h
B09
Maximum time > Qug +
529
W
E
unit16
0
10000
10
s
4.3.3.3.
Current output
Coor-
dinate
Name
Description
F01
Current
Current to be output
F02
Current mode
0
Off (default)
1
No errors
2
Error 3.5 mA
3
Error 21.8 mA
4
0 - 20mA
If the current mode is "0", meaning "Off", in apart from parameter
F02: current mode, no additional parameters of the output are visible
or adjustable.
F03
Current source
0
Specification (default)
1
Operating flow rate
2
Frequency
3
Calibration 4mA
4
Calibration 20mA
