The installation conditions for new systems according to TRG G13 and the facilitated
installation conditions for RMG turbine meters are compared in the table below.
Type of up-
stream per-
tubation
Installation
conditions
according to
TR G13
Installation
conditions for
RMG type
TME400 meters
Comments
none
Inlet  5 DN
Outlet  2 DN
Inlet  2 DN
Outlet  2 DN
The outlet pipe can also be designed as a
bend.
Inlet  10 DN
Pertubation upstream from this inlet pipe
does not have to be factored in when the
requirements for an alternating and puls-
ing flow are fulfilled.
Bend
Inlet  5 DN
Inlet  2 DN
Bends in 2
planes
Inlet  5 DN
plus 2 perforated
plate straighteners
or a bend straight-
ener
Inlet  2 DN
Gas pressure
regulating
device with an
attenuator
Inlet  5 DN
Inlet  2 DN
plus 1 perforated
plate straightener
Gas pressure
regulating
device without
an attenuator
Inlet  5 DN
plus 2 perforated
plate straightener
Inlet  2 DN
plus 1 perforated
plate straightener
Diffuser
Inlet  5 DN
plus 1 perforated
plate straightener
Inlet  2 DN
Diffuser with
swirling flow
Inlet  5 DN
plus 2 perforated
plate straightener
Inlet  2 DN
