2 Installation
Manual TME400-VMF · EN02 · 2018 September 6th
35
Figure 3: Electronics with cover of the calibration button
1 Jumper for RS 485 terminating resistor. Bridged: with 120 ; open: 0 
2 Calibration switch
3 Current module board
4 Cover plate for pressure and temperature sensor and calibration switch
5 Normal position, indicated by green arrows
