1. Introduction
1.1.
Structure of the manual
The introduction of this manual comprises two parts. The first part lists general speci-
fications; the symbols used in the manual and the structure of notices are presented
and a risk assessment is provided. The differences between the TME400-VC and
TME400-VCF turbine meters with volume converters are explained. If there is no ex-
plicit reference to differences, the TME400 is superordinate for both versions.
The unit of the turbine meter is always identified with an electric converter
with TME400-VC and TME400-VCF in this manual.
In addition, the first part includes specifications for the transport and storage of the
TME400. The second part of the introduction describes the features and areas of ap-
plication of the TME400; basic standards are listed and the pressure and temperature
ranges in which the TME400 can and may be used are pre-adjusted.
The second chapter describes the electrical and mechanical commissioning of the
TME400. An explanation of how to achieve the reliable commissioning of the meter
and high precision is provided.
The third chapter explains the displays of the TME400. It explains resetting, booting
and replacement of the battery.
The settings of the TME400 are explained in chapter four. In particular, all adjustable
parameters are provided there with some explanations.
The fifth chapter summarizes the technical data and the sixth chapter provides a list
of error messages.
The appendix provides details about the Modbus, measurements, type plate and seal
plans. Then the certificates and approvals are listed.
