4 Operation
Manual TME400-VMF · EN02 · 2018 September 6th
50
Access level
Access right
A
Display values, change not possible
N
Parameter for which no password is necessary for use
C
Code word
Entry of a code word is necessary to change the parameter.
E
Calibration button
Custody-transfer variant TME400-VMF:
Custody-transfer display values / parameters, use of the
calibration button is necessary.
Non-custody-transfer variant TME400-VM:
Entry of the code word is adequate.
4.2.
Programming
There are five buttons available on the front foil for programming of the TME400. Al-
ternatively, you can carry out programming via the RMGView
EVC
operating software
(see chapter 4.4 RMGViewEVC).
4.2.1.
Programming with the programming buttons
Basically, you proceed as follows for the programming:
• First check the protection status of the coordinate. When parameters are not
protected, you can carry out changes, as described below without additional
measures.
• With parameters protected by code word, you must enter it first in coordinate
Z15. Please read how to make the entry as below.
• With parameters protected for custody-transfer applications, you must press
the calibration button first.
