RMG TME400-VMF User Manual

5 Technical data
MANUAL TME400-VCF · EN08 · July, 01
st
2021
83
5. Technical data
5.1.1.
Device types
Reed or transistor (with connected turbine meter)
Pulse input
Reed or transistor
Current output
Current loop connection
(current supply via this current output possible)
Wiegand (with connected turbine meter)
Use
Direct installation on the TME400 turbine meter instead
of the meter head
Pulse input
Wiegand
Current output
Current loop connection
(current supply via this current output possible)
5.1.2.
Inputs
Volume
Reed
Pulse frequency
0 Hz ... 4 Hz
Pulse width
 20 ms
Voltage
low:  0.9 V high:  2.2 V
Wiegand
Pulse frequency
0 Hz ... 400 Hz; with battery operation
Pulse width
 5 s
Voltage
min. 1 V max. 5 V (determined by sensor)
5.1.2.1. Power supply
Power supply
Internal battery
Lithium cell 3.6 V; in the device (battery pack)
External 6-24 V DC via X6
via U
ext
+ battery pack (NON-Ex)
External 6-10.5 V DC via X6
via U
ext
+ battery pack (Ex)
External 6-24 V DC via X9
via current loop connection + battery pack
