4 Operation
Manual TME400-VMF · EN02 · 2018 September 6th
Figure 11: 8 columns of the coordinate system
With the TME400-VM and TME400-VMF turbine meters, the p/T and Calc.
columns cannot be selected.
With the cursor buttons (arrows)
you can reach each value by gently pressing the desired button in this coordinate
system.
Switches the column of the table from right to left
Upward movement within the column of the table:
You move from the last value of the list towards the
first value.
This is also used to adjust numbers (counting up).
Downward movement within the column of the table:
You move from the first value of the list towards the
last value.
This is used to adjust numbers (counting down).
Switches the column of the table from left to right
The following functions are triggered by pressing:
pressed < 2 seconds = display of the coordinate
pressed > 2 seconds = shows the coordinate
pressed > 2 seconds = switch to settings mode
(see below)
