Appendix
A Modbus
The TME400 has a passive RS-485 interface, which means the interface must be
supplied with power externally.
Parameterizing the Modbus
Modbus activation
H03 RS-485 protocol
0
Off
1
Modbus RTU (default)
2
Modbus ASCII
The Modbus - ID is adjusted via the coordinate H04 (default is 1)
The Modbus - Register - Offset (MRO) is entered via coordinate H05
(default is 1). The MRO applies for read and write operations.
Baud rate
H01 Baud rate RS-485 interface
0
2400 Bps
1
9600 Bps
2
19200 Bps
3
38400 Bps (default)
Interface parameters
The interface parameters can be adjusted in coordinate H02.
H02 RS-485 interface parameters
0
8N1 (default)
1
8E1
2
8O1
3
7N1
4
7E1
5
7O1
