4 Operation
Manual TME400-VMF · EN02 · 2018 September 6th
XIII. If this check shows an implausible entry, "rAnGE" will be shown briefly in the
display and the display jumps back to the original value.
XIV. If this check shows a plausible entry, "Good" will be shown briefly in the dis-
play and the value is adopted as a new value.
XV. Now you can – if necessary – change other parameters.
XVI. After about 1 minute without additional entries, the display returns to the dis-
play of the main meter.
XVII. By pressing the calibration, you close the further entry of custody-transfer pa-
rameters.
XVIII. After another minute without an entry, the change possibility is closed auto-
matically.
Some of the coordinates permit other settings as purely numerical values.
However, these other entries are assigned numbers so that the adjustment
can be carried out as described.
Example:
Current mode F02 can be deactivated or activated on various settings. This is adjust-
ed as follows:
If F02 = "0" is selected for the coordinate, the current output is switched off.
With some coordinates, a number is assigned fixed values. Instead of an
adjustment with 0, 1, ..., these numerical values are shown directly. Changes
are possible with the arrows and , then the next higher or
lower value is shown and can be adopted with .
