8.0 Supplementary Information
X Axis
This is the axis which controls the motion of the head le and
right along the X rails, driven by a belt and pulley system.
X Carriage
The X carriage contains the HeadLock™ system for attaching
dierent print heads and moves le to right along the X rails.
Y Axis
This is the axis which controls the motion of the bed forwards
and backwards along the Y rail, driven by a belt and pulley
system.
Z Axis
This is the axis which controls the motion of the gantry up and
down along the Z rail, driven by leadscrew.
Z Carriage
These are the plastic housings which hold the X rails
perpendicular to the Z axis and form the two sides of the
gantry.
